High Power PIR sensor 100W Solar Powered LED Street Light waterproof outdoor
Solar street lights are gradually replacing widely used traditional public street lights. They have a crystalline silicon solar battery to supply power, a maintenance-free controlled battery to store electricity, a ultra-bright LED lamps as light source. And they are controlled by a smart charging and discharging controller.
Composition of solar street lights
Solar lighting solutions are made up of a LED lamp, for optimal illumination, a solar panel, to capture sun rays, a storage battery, a solar street lamp controller, a lamp pole and so on. The main products are a single crystal silicon and a polycrystalline silicon solar panel, a powerful LED source, a controller set in the lamp pole , a storage battery, a valve regulated lead acid (VRLA) battery and gel battery (put underground or some certain incubator).
How do solar street lights work?
The solar panel, under the control of the intelligent controller, collects solar energy and converts it into electricity when sunrays hit solar cells. The storage battery is charged by the solar battery in daytime, and then it powers the LED lamp in nighttime. Controller plays a very important role in protecting storage battery from being overcharged or over-discharged.
| Item No. |
RYGH-H100 |
| LED Power |
90W |
| Nominal Lamp Life(h) |
50000 |
| CCT |
3000K~6500K |
| Material |
Aluminum Alloy |
| Solar Panel |
Mono 18V 90W |
| LED |
12V 100W 3030 |
| Battery |
Lithium battery 12V 42Ah |
| Install height |
11M |
| Lumen |
11000LM |
| IP Grade |
IP65 |
| Warranty |
3 years |
| MOQ |
1PC |
|
Storage Temperature
|
-40℃~+70℃ |
| Operating Temperature |
-30℃~+60℃ |
| Operating Humidity |
15~90%RH |
Brief Description:
1. Material: Aluminum + Steel glass
2. Solar Panel: 18V 90W High efficiency monocrystalline solar cell
3. LED Brand: 3030 100W 13500~14000LM
4. Battery: lithium battery 12V 42AH
5. Mounting Height:10m
6. Discharge Time: adjustable wet weather 5 to 7 days
7. Working Temperature:- 30℃ ~+60℃
8. Charge Time: 6 Hours with good sunshine
9. Lighting mode: 100% bright lighting infrared motion sensor + 60% lighting before midnight and 30%
lighting till dawn (energy saving mode to prolong backup rainy days)
Packing Details:
1.Product size: 1120*440*140mm
2.Weight(N.W): 19KG
3.Carton size: 1180*530*220mm
4.Packaging volume: 0.138CBM
5.Weight(G.W): 21KG
Application:
